Description
-
Rated Operational Current-160
-
Mechanical Life (No. of operating cycles)-25000
-
No. of Poles-4P
-
Rated Operational voltage (Ue)-415V AC
-
Rated Insulation Voltage Ui (V)-800 V
-
Conformance to Standards-IEC 60947-1, EN 60947-1, IS/IEC 60947-1 IEC 60947-2, EN 60947-2, IS/IEC 60947-2 IEC 60947-3, EN 60947-3, IS/IEC 60947-3 IEC 60947-4, EN 60947-4, IS/IEC 60947-4
-
Rated impulse withstand voltage (Uimp-8 kV
-
Operational Frequency (Hz)-50/60 Hz
-
Release Type-TM
-
Rated Short Circuit Breaking capacity Icu(kA)-DN2D MCCB 160 4P 415V AC 36kA Thermal Magnetic 50/60 Hz
-
Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC-36kA
-
Ambient temperature–5°C to 55°C
-
Suitable for isolation-Yes
-
Load-line bias-No
-
Electrical Life (Operating Cycles)-10000
-
IP Protection-IP40
-
Pollution Degree-III
-
Width(mm)-140
-
Height(mm)-179
-
Depth(mm)-96
Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.
