L&T/LK Exora RCCB 4Pole 40Amp 30ma 10kA (BG404003)

Description

• Discount Percentage-Between 0-10 %
• Operating Temperature Range–5°C to +55°C
• Electrical life (Operating Cylces)-10000
• Tightening Torque-4Nm
• Termination capacity-50 Sq. mm (Rigid) 35 Sq. mm (Flexible)
• Mechanical Life (Operating Cycles)-20000
• No. of Poles-FP
• Conformance to standards-IS 12640-1
  IEC 61008-1
• Rated Insulation Voltage Ui (V)-500V
• Rated Frequency-50Hz
• Rated Residual Making & Breaking capacity-1 kA
• Rated Impulse Voltage-4kV
• Rated Conditional SC Current-10 kA
• Current Rating-40A
• Rated Operational voltage (Ue)-415V
• Conformance to Standards-IS 12640-1 IEC 61008-1
• Sensitivity-30mA
• Length(mm)77.1
• Height(mm)-83
• Breadth(mm)-71
