Description
-
Rated Operational Current (A)-250A
-
No. of Poles-3P
-
Rated Operational voltage (Ue)-415V AC
-
Rated Insulation Voltage Ui (V)-800 V
-
Rated impulse withstand voltage (Uimp)-8 kV
-
Operational Frequency (Hz)-50/60 Hz
-
Release Type-Thermal Magnetic
-
Rated Short Circuit Breaking capacity Icu(kA)-36kA
-
Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC-50%
-
Ambient temperature–5°C to 55°C
-
Conformance to Standards-IS 60947-2, IEC 60947-2 & EN 60947-2
-
Suitable for isolation-Yes
-
Load-line bias-No
-
Electrical Life (Operating Cycles)-3000
-
Mechanical Life (Operating Cycles)-15000
-
IP Protection-IP40
-
Pollution Degree-III
-
Width(mm)-105-
-
Height(mm)-165
-
Depth(mm)-60
-
Discount Percentage-Between 0-10 %
Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.
